Ramblas eMTB

Our eMTB that’s trail tested and road ready.
244 Reviews
Rated 5 out of 5

$2,899

TEST RIDE TODAY!

Colors

20

MPH

80+

Mile Range

$2,899

TEST RIDE TODAY!

Ramblas comes out of the box as a Class I ebike, with pedal assist and a top speed of 20 MPH. Aventon’s Ramblas is built to the IP67-rated standard. IP67 rating means it’s protected against the effects of immersion in water to a depth between 15 cm and 1 meter. IP67-rated products are referred to as waterproof vs only water-resistant, so you can cross creeks, and ride in rain and mud without worry. Aventon ebikes are not intended to be subjected to a pressurized spray. Do not use a pressure washer or sprayer to clean your ebike.

MODEL
Ramblas eMTB
WEIGHT
54lbs, size large, w/o pedals
TOTAL WEIGHT LIMIT300 lbs
IDEAL USE
Mountain Biking, Urban Riding
SPEED20 MPH
RANGEUp to 80 miles
PEDAL ASSIST
3 Levels
RIDER HEIGHT
5’1″ – 6’5″
Technical Overview
Ramblas comes out of the box as a Class I ebike, with pedal assist and a top speed of 20 MPH. Aventon’s Ramblas is built to the IP67-rated standard. IP67 rating means it’s protected against the effects of immersion in water to a depth between 15 cm and 1 meter. IP67-rated products are referred to as waterproof vs only water-resistant, so you can cross creeks, and ride in rain and mud without worry. Aventon ebikes are not intended to be subjected to a pressurized spray. Do not use a pressure washer or sprayer to clean your ebike.
FRAME
6061 Single-Butted Aluminum Alloy
FORKBOREALIS: RockShox 35 Silver R 130mm travel. Coil, 44mm offset, 15×110 QR axle, 1.5″ tapered steerer tube AURORA: Rockshox Psylo Silver R, 35mm Stanchions, coil, 44mm offset, 15x110mm BOOST, 1.5″tapered steerer tube, Rebound adjust
FRAME STYLEStep-Over
RIMDouble Wall Aluminum 32h Front & Rear
SPOKESBlack Stainless 13 Gauge
TUBESButyl Rubber, Schrader Valve
HUBS15×110 32H Front, 12×148 32H Rear
TIRESS Maxxis Rekon 27.5×2.4″, M/L/XL Maxxis Rekon 29×2.4″
BATTERYAventon 708 WH. 36V LG 21700 cells
CHARGER42V 4A charger
DISPLAYLCD Smart “Easy Read”
MOTORAventon a100 mid-drive. 36v, 250W (sustained), 750W (peak), 100NM torque. IP67 rating
REAR BRAKE ROTORSram 180mm 6 bolt
FRONT BRAKE ROTORSram 200mm 6 bolt
BRAKESSram DB8 mineral 4 piston hydraulic disc brakes
REAR DERAILLEUR
Sram NX Eagle 1×12
PEDALS9/16″ Alloy Platform
CHAINRINGSram Nx 34t
CASSETTESram SX Eagle 1×12 11-50t
SHIFT LEVERSram NX Eagle 1×12 single click
SEATPOST150mm travel for size M-XL. 125mm travel for size S. 31.6mm ø. 395mm length
HANDLEBARS35mm, 9° rise, 720mm width for size S, 760mm width for size M-XL
GRIPS
Lock on
STEM35mm Ø, 40mm length
SEAT CLAMPAventon 34.9mm

Key Features

Top speed

20 mph

Range

80+ miles

Power

750W Peak

Payload

300 lb

Safety

UL Certified

Torque

100 Nm

Fully Assembled

Veteran Business

0% Financing

2 Year Warranty

In-House Repair

Mid-Drive Motor & BatteryAventon's mid-drive motor was designed to give riders full control over their riding experience. With its 250 watts of sustained power, 750 watts at peak power, 36V battery and adjustable three pedal assist levels, you can customize your ride to your liking for trail and daily commutes.
Mid-Drive Motor & Battery
Aventon's mid-drive motor was designed to give riders full control over their riding experience. With its 250 watts of sustained power, 750 watts at peak power, 36V battery and adjustable three pedal assist levels, you can customize your ride to your liking for trail and daily commutes.
100 Nm of TorqueRamblas' A100 motor produces a smoother, more natural feel when accelerating and decelerating. Its 100 nm of torque helps you quickly reach peak power when needed, then gradually tapers off to a more consistent output.
100 Nm of Torque
Ramblas' A100 motor produces a smoother, more natural feel when accelerating and decelerating. Its 100 nm of torque helps you quickly reach peak power when needed, then gradually tapers off to a more consistent output.
Ride TuneRamblas' Ride Tune enables motor customization via the Aventon app for a more personalized riding experience. Fine-tune Assistance, Max Torque, and Pedal Response, so you can optimize the full potential of your Ramblas.
Ride Tune
Ramblas' Ride Tune enables motor customization via the Aventon app for a more personalized riding experience. Fine-tune Assistance, Max Torque, and Pedal Response, so you can optimize the full potential of your Ramblas.
Over-The-Air UpdatesUpgrade Ramblas for optimal performance with its intelligent over-the-air updates that gives you instant software updates through the Aventon app without having to plug-in or go to a shop.
Over-The-Air Updates
Upgrade Ramblas for optimal performance with its intelligent over-the-air updates that gives you instant software updates through the Aventon app without having to plug-in or go to a shop.
DrivetrainRamblas comes equipped with a Sram NX 12-speed drivetrain for more efficiency to climb hills, roll around on trails and ride faster on flat surfaces.
Drivetrain
Ramblas comes equipped with a Sram NX 12-speed drivetrain for more efficiency to climb hills, roll around on trails and ride faster on flat surfaces.
Dropper PostRamblas' dropper post enhances control and comfort right from the handlebars using the dropper level. Drop it low for more room in the cockpit while navigating steep or technical terrain, or raise it up for a more efficient riding position.
Dropper Post
Ramblas' dropper post enhances control and comfort right from the handlebars using the dropper level. Drop it low for more room in the cockpit while navigating steep or technical terrain, or raise it up for a more efficient riding position.
Ramblas DisplaySame great features as Aventon's Full Color Display, only more compact. The Ramblas Display is slightly smaller and repositioned to protect it from unforeseen circumstances while hitting the trail or streets.
Ramblas Display
Same great features as Aventon's Full Color Display, only more compact. The Ramblas Display is slightly smaller and repositioned to protect it from unforeseen circumstances while hitting the trail or streets.
Hardtail FrameRamblas' hardtail frame is a workhorse for the all-terrain. It's lightweight, durable, and reliable, giving you the confidence you need on mountain trails and rough roads.
Hardtail Frame
Ramblas' hardtail frame is a workhorse for the all-terrain. It's lightweight, durable, and reliable, giving you the confidence you need on mountain trails and rough roads.
Pedal AssistSwitch between 3 levels of pedal assist: eco, trail, and turbo, to get more in the mountains and on the streets. Add a boost to the way you move with a top speed of 20 mph and up to 80 miles in range.
Pedal Assist
Switch between 3 levels of pedal assist: eco, trail, and turbo, to get more in the mountains and on the streets. Add a boost to the way you move with a top speed of 20 mph and up to 80 miles in range.
BrakesEnhance your speed control on steep slopes and loose terrain with Ramblas' Sram DB8 mineral 4 piston hydraulic disc brakes. With four pistons, Ramblas' brakes offer superior modulation, meaning more brake fluid is distributed across a larger surface area, allowing you to stop when you need to most.
Brakes
Enhance your speed control on steep slopes and loose terrain with Ramblas' Sram DB8 mineral 4 piston hydraulic disc brakes. With four pistons, Ramblas' brakes offer superior modulation, meaning more brake fluid is distributed across a larger surface area, allowing you to stop when you need to most.
ForkRamblas' Rockshox 35 suspension with 130mm of travel allows riders to find comfort on the roughest of terrain. Roll over rocks, tree roots, and rugged roads and let the suspension take care of the rest.
Fork
Ramblas' Rockshox 35 suspension with 130mm of travel allows riders to find comfort on the roughest of terrain. Roll over rocks, tree roots, and rugged roads and let the suspension take care of the rest.

Playlist

7 Videos

Geometry

Ramblas eMTB is available in 4 sizes to suit most adults

Frame SizeSmallMediumLargeExtra Large
Seat Tube Length380mm410mm450mm490mm
Top Tube Length Horizontal594.5mm616.5mm642mm668mm
Bottom Bracket Drop55mm55mm55mm55mm
Head Tube Length125mm125mm135mm135mm
Head Tube Angle66.5°66.5°66.5°66.5°
Seat Tube Angle74.5°74.5°74.5°74.5°
Rear Chainstay Length465mm465mm465mm465mm
Front Wheel Center720mm744mm770.5mm796mm
Wheelbase1179.5mm1203mm1230mm1256mm
Reach415mm432.5mm455mm481mm
Stack Height640mm656.5mm665mm665mm
Fork Length530mm547mm547mm547mm
Fork Offset44mm44mm44mm44mm
Trail108.6mm117mm117mm117mm
Standover683mm702mm712mm719.5mm
Rider Height (Range)155 – 165 cm 5’1″ – 5’5″165 – 176 cm 5’5″ – 5’9″177 – 188 cm 5’10” – 6’2″188 – 195 cm 6’2″ – 6’5″
