Radster Trail

Off-road fun meets eye-catching style
1,713 Reviews
5/5

Colors

20-28

MPH

65+

Mile Range

The Radster Trail is an electric off-road bike with the power to do anything, and the range to go anywhere. The 100 Nm motor makes quick work of hills, the 28 mph top speed promises fast-paced fun, and with two frame sizes for a personalized fit, it’s so comfortable that you’ll barely feel like you’re roughing it.

Fully Assembled

Veteran Business

0% Financing

2 Year Warranty

In-House Repair

Battery

15Ah 720 Wh Safe Shield Advanced Semi-Integrated Battery, Samsung 50GB or LG M50LT cells, UL Certified to UL-2271.

Charger


48VDC, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets

Class


Class switchable 1 to 3. Ships in Class 2 status

Display


Rad custom color display. See Display section below for details

Hub Motor


Rear hub 750W, 100 Nm torque
Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions

Lights


Auto-on feature
Front: ~200 lumens LED headlight with built-in reflector
Rear: Integrated taillight with brake light and turn signals

Pedal Assist


Torque sensor, 5 PAS Levels, plus a zero assist option

Range


Estimated 25-65 miles per charge

Throttle

Half twist throttle

Top Speed

20-28 mph

USB Ports

Optional, sold separately



Bell

Yes

Brakes

Tektro Hydraulic Disc E350

Brake Lever(s)

Tektro semi-metallic P20.11

Brake Pad Material

Brake Rotors
180mm x 1.8mm

Crank Set

50T with dual sided chain ring cover, 170mm crank arms

Derailleur

Shimano 8-speed

Fenders

Front and full rear alloy mudguard

Derailleur

n/a

Fenders

Included, full coverage front and rear

Fork

Rigid steel fork

Fenders

Front and full rear alloy mudguard

Frame

Aluminum

Freewheel/Cassette

8-speed freewheel 11-34T

Gearing

1×8 speed

Grips

Ergonomic rubber comfort grips

Handlebar

Aluminum, 710mm wide

Kickstand

Side mounted, adjustable angle kickstand

Pedals

Alloy Platform, Boron axle with reflectors, standard 9/16″ X 20 TPI threading

Rear Racks

Integrated, 55 lb (25 kg) carrying capacity

Saddle

Padded sport saddle with shallow anatomic cut-out and contoured sides

Seatpost

Regular: 350 mm x 31.6 mm
Large: 400 mm x 31.6 mm

Seatpost Clamp

38.1 mm

Shifter

Shimano 8-speed thumb shifter

Stem

40mm A-head

Tires

Kenda Havok 27.5″ X 3.0″ with puncture protection and tan sidewall





Rider Heights5’7″-6’4″ (170-193 cm)
Bike Weight78 lb (35.4 kg), 69 lb (31.3 kg) with battery removed
Payload370 lb, 290 lb. max rider
Rear Rack Payload55 lb (25 kg)
Handlebar Height45.25″ (114.9 cm)
Reach15.6″ (397 mm)
Seat HeightFrom ground: 31.5″ – 39″ (80 – 99 cm)
From pedal bottom stroke: 27″ – 35″ (69 – 89 cm)
Standover Height24″ (61 cm)
Stepover Height24″ (61 cm)
Total Length76″ (193 cm)
Wheelbase47.4″ (120.3 cm)
Seat Tube Length16.8″ (426 mm)
