Rift Step-Over

All-terrain fat tire ebike
37 Reviews
5/5

$1,695
+ Tax and Assembly

350 lbs.

Capacity

20-28

MPH

60

Mile Range

$1,695
+ Tax and Assembly

Crafted for resilience in tough terrains, the Rift fat tire electric bike embodies adventurous spirit with accuracy and steadiness. Its quad piston brakes, immense range and strength, combined with class 2-3 features, seamlessly merge adaptability and comfort for the ultimate ride.

Key Features

750W, 95nm

20-28mph

Smooth Assist

60 Mile Range

Hydraulic Brakes

26" x 4" Tires

Play Video

Bike Goes Great With

Fully Assembled

Veteran Business

0% Financing

1 Year Warranty

In-House Repair

MOTOR

48V Geared Hub, AKM Angled Gears, 750w Sustained
BATTERY

48V 20ah Reention Mammoth LG Cells, Smart BMS
DISPLAY

KD218 Adjustable Speed Color Display
PAS SENSOR

Integrated Sensitive Cadence Sensor
BRAKES

180mm 4-piston Hydraulic Disc Brakes w/ Cut-Off Sensor
FORK

Hydraulic Lockout 120mm Travel Suspension
TIRES

Kenda Krusade Anti-puncture tires 26×4.0″
THROTTLE

Left-hand Thumb Throttle
HANDLEBARS

680mm MTB double butted 9º Riser bars
CONTROLLER

48V 30A Sine-wave
GRIPS

Ergonomic Locking Rubber Grips
SHIFTERS

Shimano 8-speed SL-M315
GEARING

44T Prowheel Alloy Chainring
CASSETTE

Shimano 11-32T
DERAILLEUR

Shimano RD Altus
CHAIN

KMC Z8.3 8-speed chain
SPOKES

Stainless Steel, 13G F – 12G R
SADDLE

KNUS Ergo Gel MTB Saddle
SEAT POST

30.9mm, 350mm long Easton Dual Bolt
STEM

50mm Ext. 31.8mm Bar Clamp
RACK

150lb rated loading weight with pannier side mount
FRONT LIGHT

Buchel Shiny 80, Ultra-bright 80 lux headlight
REAR LIGHT

Velo Edge 48V, With Brake Light
ADDITIONAL

Rear Rack Bungee, and Chainstay Guard

Bike Weight

84.5lbs

Weight Capacity

350lbs

Rider Height Range

5’6″-6’4″

A – Maximum Seat Height

1118mm

B – Minimum Seat Height

851mm

C – Stand-Over Height
749mm

D – Wheelbase

1183mm

E – Top Tube Length

576mm

F – Head Tube Length

160mm

G – Seat Tube Length

432mm

H – Chainstay Length

500mm

I – Fork Length

517mm

J – Head Tube Angle

68°

K – Seat Tube Angle

72.5°

L – Stack

670mm

M – Handlebar Reach

390mm

N – Total Length

1915mm

O – Handlebar Height

1080mm
